EVO DRAIN FLOORS

VOGI EVO series of floor drains consist of 12 different models. Every version consist a different main body construction (horizontal, vertical or horizontal double). A trap (dry or wet) and telescope with stainless steel grate. The set include a waterproofing membrane.

flor drain icons.jpg

HOW THE EVO DRAIN FLOOR IS BUILD?


EVO MODELS OF FLOOR DRAINS

  • Horizontal outlet

  • Wet siphon

  • Inox grate

  • Isolate membrane 24 x 24

X1B

  • Horizontal outlet

  • Dry siphon

  • Inox grate

  • Isolate membrane 24 x 24

X2B

  • Vertical outlet

  • Wet siphon

  • Inox grate

  • Isolate membrane 24 x 24

Y1B

  • Vertical outlet

  • Dry siphon

  • Inox grate

  • Isolate membrane 24 x 24

Y2B

  • Horizontal double

  • Wet siphon

  • Inox grate

  • Isolate membrane 24 x 24

Z1B

  • Horizontal double

  • Dry siphon

  • Inox grate

  • Isolate membrane 24 x 24

Z2B

  • Horizontal outlet

  • Wet siphon

  • Tile in grate

  • Isolate membrane 24 x 24

X1C

  • Vertical outlet

  • Dry siphon

  • Tile in grate

  • Isolate membrane 24 x 24

X2C

  • Vertical outlet

  • Wet siphon

  • Tile in grate

  • Isolate membrane 24 x 24

Y1C

  • Vertical outlet

  • Dry siphon

  • Tile in grate

  • Isolate membrane 24 x 24

Y2C

  • Horizontal double

  • Wet siphon

  • Tile in grate

  • Isolate membrane 24 x 24

Z1C

  • Horizontal double

  • Dry siphon

  • Tile in grate

  • Isolate membrane 24 x 24

Z2C

DIFFERENCE BETWEEN SPHONS

     WET SIPHON

    DRY SIPHON

Designed for interior application where frequent use of the drain is present, such as bathrooms. As water is collected it creates natural barriers which prevent bad odours from entering the building.


Designed for use in areas where water is only present at irregular intervals such as boiler rooms, basement, garages or aoutdoors. Foul odours are stopped by the sealed flap which only opens in the moment when water is present. This type of siphon can also be used in places where temperatures fall below zero.

ADVANTAGES OF FLOOR DRAINS

Installation of the product in the floor is extremely easy because to the possibility of height adjustment and rotation of the telescope.

The grate is made in an extremely attractive form made of havy, ground and polished stainless steel.
The structure of the steel prevents scratches, and the shape of the grate covers all the plastic edges of the grille body after installation.

A special grate allows the tile to be instaled in the center thats why we obtain an extremely aesthetic finish of the bathroom floor.

The attached sealing sleeve provides a moisture barrier in the floor by compensating for stresses and masking scratches in the substrate.
